Quick-Action Compass
Series New Master 2 – Colours of Graffiti
with plastic pressure levers

Quick-Action Compass
Series New Master
new design, very comfortable model, pressure lever mechanism with automatic locking of the spindle and precise setting of centre wheel, 2 knee joints, by attaching adaptor with 4 mm dia. spigot, all commercial technical pens can be used, compass length 165 mm, working range up to 330 mm Ø, with extension bar 570 mm Ø (delivery without extension bar), lead box, in transparent
covered box,
Material zink diecasting

New Master 2 plastic pressure levers
compass with colour motive

Ref. 421636 motive Colours of Graffiti* EAN 4011123661906

* (colours are subject to change without notice, updated trend colours please see price list)


Interested in the product?
• As a commercial reseller in our industry, you can buy directly from us using the
contact form.
• As a commercial end user (B2B) or private end user (B2C), you can purchase our products from our trading partners (list of dealers)

Note: Article search on the Internet via Ref. no. or EAN no. possible.


Series New Master, Lead compasses, Insert compasses, Pump compasses, Geometric compasses, Quick action compasses, School compasses, Beam compasses, Dividers, Technical drawing compasses, Part compasses, Telescope compasses, Turning bow-spring, dividers, Drawing items, Drawing technique

SKU: 421636 Category: Tag:

In these assembly instructions we will show you step by step how to assemble an extension bar on a compass:

Suitable extension bar for this compass: Ref. 379200

More technical details can be found in our compass lexicon.
